- Machining on CNC horizontal boring machines
- Machining on CNC lathes
- Milling, grinding
- Bending on a CNC press brake
- Rolling on four-roller machine with pre-bending
- Plasma cutting
Four-roller hydraulic sheet roller HRB-4 3025
The roller has four rollers which enables pre-bending of the sheet prior to actual rolling.
DURMA HRB-4 3025 also rolls conical parts up to 1.5 times the diameter of the top roller.
Technical parameters
Working length: 3 100 mm
Maximum sheet thickness: 25 mm
Top roller diameter: 400 mm
CNC hydraulic press brake E-40300
The CNC controlled press brake guarantees maximum accuracy, speed and reliability. The press enables bending sheet from carbon steel up to a thickness of 10 mm and length of 4050 mm.
Technical parameters
Working length: 4 050 mm
Stroke: 245 mm
Press force: 300 t
Horizontal NC boring machine WHN 13.4 a WHN13.8-CNC
max. table size: 1 800 mm x 1 600 mm
max. transversal table travel: 3 500 mm
max. vertical travel: 2 000 mm
Horizontal CNC boring machine W 100
max. table size: 1 250 mm x 1 250 mm
max. transversal table travel: 1 600 mm
max. vertical travel: 1 220 mm
MGM Omnicut 5000G - CNC burning machine
burner: gas, plasma
width : 2 500 mm
length : 8 000 mm
max. material thickness: 200 mm, plasma max. 25 mm
tilting plasma head with tilt +/- 45°
perpendicular pipe cutting Ø 100 - 600 mm, thickness walls max 20 mm
PIERCE SCORPION 2 500 Centre lathes
max. turning diameter above lathe bed: 655 mm
max. turning diameter above lathe carriage: 390 mm
max. centre distance: 5 000 mm
max. turning diameter above lathe bed: 500 mm
max. turning diameter above lathe carriage: 250 mm
max. centre distance: 2 000 mm
max. turning diameter above lathe bed: 630 mm
max. turning diameter above lathe carriage: 340 mm
max. centre distance: 4 000 mm
CNC lathes
max. turning diameter above lathe bed: 630 mm
max. turning diameter above lathe carriage: 350 mm
max. centre distance: 1 200 mm
CNC lathes GT380LA
max. turning diameter above lathe bed: 700 mm
max. turning diameter above lathe carriage: 570 mm
max. centre distance: 1440 mm
Carousel
max. machining diameter: 950 mm
max. clamping diameter: 800 mm
max. workpiece height: 420 mm
Milling machines
max. table size: 600 mm x 1 400 mm, 300 mm x 800 mm
Hobber for gear manufacture
module: 1 to 8
max. wheel diameter: 750 / 1 000 mm
max. clamping diameter: 850 mm
Round grinder
rotating diameter: 650 mm
max. centres turning diameter: 3 000 mm
max. hole diameter: 120 mm
max. hole length: 140 mm
Flat grinder
max. table size: 600 mm x 200 mm
max. workpiece height: 150 mm
Slotting machines, Drilling macines, Tapping (thread)
Shearing machines up to thickness 16 mm
Small rollers
Band saw – cutting range: D345, 510x345
